Tune KillHill / ClimbHill Endurance Purple Violet Limited Edition 15x110 / 12x148 Boost XD 32h SET

-TUNE ClimbHill Boost 32 12mm Alu Caps, XD/XDR 3T End, Bearing Endurance, violet 4062266269238
- TUNE KillHill Boost 32 15mm Alu Caps, Bearing Endurance, violet 4062266269184

Premium lightweight SET of front and rear hubs made in Germany

Class: Endurance

Use: Gravel, MTB, XC, All Mountain, Trail, Enduro

Weight: 124g + 220g

Custom production! More info about TUNE!

TUNE products are custom-made in the Black Forest (Germany) engineering center. CNC machined from aircraft aluminum, hand-pressed bearings. Production time 1-2 weeks.

Technical specification:

Colours: available in all Tune anodised colours
Max. Rider weight: 100kg
Max. System weight: 115kg
Weight: 230.7g/12X148mm-6 bolt_ 226.3g/12X148mm-centerlock_ 228.3g/12X142mm-6 bolt_ 223.9g/12X142mm-Centerlock
Hub hole count: 28 or 32 for 3-cross pattern
Max Spoke Tension: 1100N
Axle type: available in 5mmX135mm /12mmX142mm /12X148mm with Aluminum Endcaps
Bearing Type: standard on the right-side and double sealed Endurance on the left-side
Freewheel types: 3Teeth Titanium Technology reinforced Endurance
Freewheel standard: available with XD, XDR, Shimano HG10 or Shimano HG11
Brake Interface: available in Centerlock and in 6-Bolt for 5mm, 12mm axles

Dimensions
for axle type: 148mm
Flange distance left: 36.3mm
Flange distance right: 24.1mm
Pitch circle left: 55.5mm
Pitch circle right: 55.5mm
Spoke hole diameter: 2.4mm

Colours: available in all Tune anodised colours
Max. Rider weight: 100kg
Max. System weight: 115kg
Weight: 118.0g/15X100mm-centerlock_ 122.4g/15X100mm-6Bolt_ 119.4g/15X110mm-centerlock_ 123.8g/15X110mm-6Bolt
Hub hole count: 28 or 32 for 3-cross pattern
Max Spoke Tension: 1100N
Axle type: available in 5mmX100mm/ 12X100mm/ 15mmX100mm/ 15mmX110/ with Aluminum Endcaps TorqueCaps-15mmX110mm with Carbon Endcaps
Bearing Type: standard
Brake Interface: available in Centerlock and 6-Bolt for 5mm, 12mm and 15mm axles and 6-Bolt only for TorqueCaps
Dimensions
for axle type: 110mm
Flange distance left: 27.4mm
Flange distance right: 37.0mm
Pitch circle left: 55.5mm
Pitch circle right: 55.5mm
Spoke hole diameter: 2.4mm

MADE IN GERMANY
