INTEND ORIGINALS EDGE: OPTIMIZED 29" 150-180mm

NOTE: LIMITED SMALL-BATTERY PRODUCTION - PRE-ORDER IS POSSIBLE.

EDGE

• New: Closed damping cartridge
• New: Travelizer Air Spring
• New: Racing Bro's Dust Wipers
• The one of a kind enduro upside down fork
• Made for the roughest terrain & conditions
• Utilizes new BCT crown
• Designed, engineered & tested in Freiburg / Germany
• Assembled 100% in-house and by hand – One at a time

UPSIDE DOWN ENDURO BENCHMARK

The Intend Edge suspension fork is what started it all - the latest iteration brings together years of development to achieve a level of performance we're proud of.
This unique enduro-oriented upside down fork will give you all the confidence you need to approach your next race or go KOM hunting.
The extra-strong legs and reinforced crown will support you with sufficient stiffness no matter the type of trail or the speed at which you head down.
Our DH-ready damping and air suspension provide unmatched suppleness and a natural, predictable feel. In case you want more progression: Two bottom caps with alternating progression are included.
Our forks are extremely easy to service and no special tools are required. Changing the stroke is also easy, no additional air shaft is needed! Simply connect the shock pump and turn 360° for +/-1 mm stroke.

underline;">Description

• RideStyle
  Enduro
• Travel Range
  150-180mm, adjustable in 1mm steps
• Wheel Size
  29” only
• Spring Type
  Air spring
• Dumping
  Closed cartridge, self-bleeding
• Adjustments
  Rebound / Compression / Air spring / Progression
• Weight
  2130g
• Color
  Black anodized
• Lowers
  Champagner coated tubes with pressed on dropouts

  USD forks in general not 100% compatible with steel braided hoses (Stahlflexleitungen)

Technical data

• Fork Offset / Rake
  44mm
• Steerer Tube Length
  240mm
• Stanchion Diameter
  45mm
• Axle to Crown
  180mm (591.5) / 170mm (581.5) /160mm (571.5) ...you get the idea!

• Steerer Tube
  Tapered 1 1/8" - 1.5" (inner diameter: 23mm)
• Dropout
  15mm x 110mm boost
• Brake mount
  180mm or 203mm brake mount included

*AI generated translation!*
